2,5mm stereo plug with metal shell and gold plated contacts for max 6,3mm cable *new*

2,5mm stereo plug ie the smallest plug size which can be seen on some mobile phone hands free devices or some other special appliances where designers wanted to have a connector, that is as small as possible.

Connector’s technical details:

• Material:
  • Metal housing
• Max compatible cable diameter:
  • 6,3mm
• Connection type:
  • Solder
  • "The solder pad is impossibly small to solder" they said! No worries as a hint, bend the stripped wire around the solder point and solder it horizontally into it’s place. Works like a charm!
• Strain relief:
  • Crimp type
• Connector outer diameter:
  • 8,5mm
• Connector overall length:
  • 39mm
• Typical connection in audio use:
  • Stereo signal:
    • Tip:
      • Left signal + (usually red)
    • Ring:
      • Right signal + (usually black or white)
    • Sleeve:
      • Ground - (usually cable’s braided copper shield)
  • Balanced signal:
    • Tip:
      • Signal + (usually red)
    • Ring:
      • Signal - (usually blue or black)
    • Sleeve:
      • Ground - (usually cable’s braided copper shield)
